Guangdong Xinye Intelligent Label Co., Ltd.'s high-temperature RFID tags have proven their resilience in demanding applications such as automotive manufacturing, downhole oil and gas pipelines, laundry, and high-pressure sterilization.
Our high-temperature metal tags utilize RFID technology and can be read at frequencies of 125 kHz, 13.56 MHz, and UHF 860-960 MHz, supporting a variety of packaging materials including nylon, PPS, ABS, ceramic, FR4, stainless steel, and proprietary high-temperature materials. Standard heat-resistant RFID tags can withstand temperatures of 200°C to 230°C, while extreme and ultra-high temperature RFID tags can endure up to 300°C and 400°C. Common applications for heat-resistant RFID tags include automotive manufacturing, downhole drilling, and any manufacturing process requiring high temperatures.
High-temperature RFID tags are designed for extreme heat applications, with encapsulation ensuring protection from high temperatures and stress during manufacturing and industrial processes. For industrial systems utilizing RFID technology, extreme-temperature RFID tags are chosen by various industries to withstand the harsh conditions of certain factory and warehouse environments.
Ultra-High Temperature Anti-Metal RFID Tags
Wear-resistant, acid and alkali resistant, corrosion-resistant, with the option for surface encoding.
| Material | Stainless Steel |
| Storage Temperature | -40°C to 120°C |
| Operating Temperature | 300°C+ (8H long-term), 350°C (6H short-term) |
| Waterproof Rating | IP68 |
| Read Range | ≥6M |
| Write Cycles | 100,000 times |
| Data Retention | 10 years |
| Application | Steel mills, foundries, high-temperature furnaces |
| Chip | Higgs9 |
| Frequency | 902-928MHZ |
| Dimensions | 38×38×11.5mm |
| Weight |
65g |
UHF RFID Oil Drill Pipe Tags
Suitable for downhole and surface drill pipe tracking, underwater oil pipeline tracking, blowout preventers, and wellhead applications.
| Dimensions | Ø25.3×8mm |
| Material | Stainless Steel + Engineering Plastic |
| Color | Silver Gray |
| Mounting Method | Embedded |
| Weight | 17g±10% |
| Protocol | ISO 18000-6C |
| Frequency | 902-928MHz (US), 865-867MHz (EU) |
| Chip | Higgs9 |
| Memory | EPC 96bits, USER 512bits |
| Read Range (Fixed Reader) | ≥1m |
| Read Range (Handheld) | ≥0.5m |
| Protection Rating | IP68 |
| Operating Temperature | -40°C to 300°C |
| Pressure Resistance | 120MPa |
| Working Temperature | -40°C to 80°C |
ABS High-Temperature RFID Tags
Suitable for outdoor asset inventory, pallet management, warehouse location management, electric vehicle management, and logistics turnover. ABS anti-metal tags, protected by a casing, offer a high protection rating. Depending on their antenna structure, certain models deliver excellent performance on both metal and non-metal surfaces.
| Material | ABS |
| Color | Customizable |
| Mounting Method | Screw/Rivet |
| Protocol | ISO 18000-6C |
| Frequency | 902-928MHz (US), 865-867MHz (EU) |
| Chip | Alien Higgs9(Customizable) |
| Memory | EPC 96bits, USER 512bits |
| Read Range (Fixed Reader) | ≥9m |
| Read Range (Handheld) | ≥4m |
| Protection Rating | IP65/IP68 |
| Storage Temperature | -40°C to 200°C |
| Working Temperature | -40°C to 80°C |
FR4 PCB High-Temperature RFID Tags
PCB tags are made with FR4 substrate and designed for attachment to assets, servers, pallets, or rigid items, excelling in high-temperature RFID applications. This material is characterized by high temperature resistance, high protection rating, and reliability, making it widely used in asset inventory and pallet management.
| Dimensions | Customizable |
| Material | FR4 |
| Color | Black/White |
| Mounting Method | Screw/Rivet/Cable Tie |
| Protocol | ISO 18000-6C |
| Frequency | 902-928MHz (US), 865-867MHz (EU) |
| Chip | Alien Higgs9 (Customizable) |
| Memory | EPC 96bits, USER 512bits |
| Read Range | 0.1-5m |
| Protection Rating | IP67 |
| Storage Temperature | -40°C to 150°C |
| Working Temperature | -40°C to 80°C |
PPS High-Temperature RFID Tags
PPS high-temperature electronic tags are specifically designed and manufactured for harsh environments, capable of withstanding 200°C for extended periods and enduring acid and alkali conditions with stable and reliable performance.
Features a globally unique identification code, installation using rivets or screws.
Widely used in asset management, warehouse pallet management, power equipment inspection, industrial high-temperature environments, and equipment management in strong acid/alkali conditions.
| Dimensions | Customizable |
| Material | Polyphenylene Sulfide (Customizable) |
| Color | Customizable |
| Protocol | ISO 11784/85, 15693, 14443A, ISO/IEC 18000-6C |
| Frequency | 13.56MHz |
| Chip | I-CODE SLI (Customizable) |
| Memory | 1KB (Depends on Chip) |
| Read Range | 5-10cm |
| Protection Rating | IP67 |
| Storage Temperature | -40°C to 220°C |
| Working Temperature | -40°C to 220°C |
High- Temperature Ceramic RFID Tags
These are ultra-high-frequency anti-metal tags with high-temperature and high-pressure resistance, compact size, and high sensitivity, suitable for tool management and tracking various industrial assets. Ceramic RFID tags also offer heat resistance, water resistance, and chemical resistance.
Main Applications
- Electronic component management in the automotive industry, such as circuit boards and parts.
- Surgical and medical equipment management in the healthcare industry.
- Tool management in industrial and manufacturing settings.
| Dimensions | 25×25mm (Customizable) |
| Material | Ceramic |
| Color | Black (Customizable) |
| Protocol | ISO 18000-6C |
| Frequency | 902-928MHz |
| Chip | Alien Higgs9 (Customizable) |
| Memory | EPC 96bits, USER 512bits (Depends on Chip) |
| Protection Rating | IP65 |
| Storage Temperature | -40°C to 200°C |
| Working Temperature | -40°C to 80°C |
Guangdong Xinye Intelligent Label Co., Ltd. offers customized high-temperature RFID tags. All extreme-temperature RFID tags come with multiple options, including antenna design, shape, frequency, read distance, and memory, allowing us to assemble products tailored to your requirements. Below is a partial list of our high-temperature RFID tag products. Let us know which type of heat-resistant RFID you need, and our technical sales team will respond promptly to assist you!
